RS130 SPECIFICATIONS
Axles
8" x 4" .188 Wall
Spindle
2-1/2"
Hub
8 Bolt
Hub Capacity
8000 lb Capacity
Bearings
Taper Roller
Steering Rod
1-1/8"
Tongue
Quick Hitch
Reach
3-1/2" O.D. .188 Wall
Stakes
38" - 42" Adjustable
Track
86"
Approximate Weight
815 lbs.
  • Steering Pins - Tapered pin with slotted nuts so you can tighten steering again and again.
  • Tie Rod Ends - Tapered hardened bronze bushings wiht dust cap to keep dirt out.
  • Wheel base - 15' wheel base standard or varied lengths available on request.
  • Wide variety of wheels and tires.
